Description
Plate Dimensions 146mm (W) x 86mm (H) x 9.5mm (D)
Plate Design & Finish Rounded Profile Polar White Front Plate & Rocker Switch: Urea Rear Housing: Nylon Terminals: Brass Terminal. Screws: Steel & Yellow Passivated. Contacts: Silver “on-lay” Copper / Brass. Internal Busbars: Formed Pressed Brass. PCB: Mixed Components. Earth Strap: Mild Steel
Maximum Voltage 250V~ 50Hz
Load Rating 13A
Plate Fixing Centres 120.6mm
Terminal Size 5mmø
Terminal Torque 1.2Nm
Terminal Capacity 3 x 2.5mm2 or 2 x 4mm2
Single Pole Yes
Twin Earth Terminals Yes
USB Charging Output Total 5V DC, 2.1A
Number Of USB Outputs 1
USB Type USB Type “A”
USB Standby Current 2mA
Product Markings USB 5V 2.1A
Ingress Protection IP20
Back Box Depth 25mm Minimum
Termination Type Screw
Operational Temperature -5°C to +40°C
